Week 2 + 3: HydraBoa (-e and -c due October 8, -i due October 15)

In this assignment you'll implement a compiler for a small language called Boa and extend it with dynamic features. We'll call the language Boa and the whole runtime system and CLI tooling HydraBoa. The main features are let bindings and binary operators. The key difference between this language and what we implemented in class is that there can be multiple variables defined within a single let. This language implementation has three modes, Ahead-of-Time (AOT), Just-in-Time (JIT), and an interactive REPL mode.

  • Part 1: Supporting the Boa Language and AOT compilation of Boa files with a generated assembly file. This is with the -c compile flag to the main program.
  • Part 2: JIT compilation of Boa files with an evaluation at runtime, using dynasm. This is with the -e eval flag to the main program.
    • The -g flag prints the evaluation and writes out AOT assembly for debugging purposes.
  • Part 3: A REPL for Boa. This is with the -i interactive flag to the main program.

(It's common for languages to have multiple implementations and different tooling depending on the implemenation. For example JavaScript is a language, while NodeJS and V8 are implementations of JavaScript with various features, CLI options, etc. The same can be said for Python, where CPython and PyPy are both implementations with their own features and quirks. Same for Java and OpenJDK versus OracleJDK, C and clang vs gcc, and so on. So Boa is the language – its syntax and definition of what it's supposed to do. HydraBoa is our full implementation with its own CLI tooling, etc.)

Setup

Get the assignment at https://classroom.github.com/a/RfezDfWu. This will make a private-to-you copy of the repository hosted within the course's organization. You can also access the public testing infrastructure code directly from this public URL.

Part 1: The Boa Language

In each of the next several assignments, we'll introduce a language that we'll implement. We'll start small, and build up features incrementally. We're starting with Boa, which has just a few features – defining variables, and primitive operations on numbers. Part 1 is about making an Ahead-of-Time (AOT) compiler for the Boa Language.

There are a few pieces that go into defining a language for us to compile:

  • A description of the concrete syntax – the text the programmer writes.
  • A description of the abstract syntax – how to express what the programmer wrote in a data structure our compiler uses.
  • A description of the behavior of the abstract syntax, so our compiler knows what the code it generates should do.

Concrete Syntax

The concrete syntax of Boa is:

<expr> :=
  | <number>
  | <identifier>
  | (let (<binding> +) <expr>)
  | (add1 <expr>)
  | (sub1 <expr>)
  | (+ <expr> <expr>)
  | (- <expr> <expr>)
  | (* <expr> <expr>)

<binding> := (<identifier> <expr>)

Here, a let expression can have one or more bindings (that's what the <binding> + notation means). <number>s are in base 10 and must be representable as an i32. <identifier>s are names and should be limited to alphanumeric characters, hyphens, and underscores, and should start with a letter. (The sexp library handles more than this, but this keeps things nicely readable.)

Abstract Syntax

The abstract syntax of Boa is a Rust enum. Note that this representation is different from what we used in Adder.

enum Op1 {
    Add1,
    Sub1
}

enum Op2 {
    Plus,
    Minus,
    Times
}

enum Expr {
    Number(i32),
    Id(String),
    Let(Vec<(String, Expr)>, Box<Expr>),
    UnOp(Op1, Box<Expr>),
    BinOp(Op2, Box<Expr>, Box<Expr>)
}

Semantics

A "semantics" describes the languages' behavior without giving all of the assembly code for each instruction.

A Boa program always evaluates to a single integer.

  • Numbers evaluate to themselves (so a program just consisting of Number(5) should evaluate to the integer 5).
  • Unary operator expressions perform addition or subtraction by one on their argument. If the result wouldn't fit in an i32, the program can have any behavior (e.g. overflow with add1 or underflow with sub1).
  • Binary operator expressions evaluate their arguments and combine them based on the operator. If the result wouldn't fit in an i32, the program can have any behavior (e.g. overflow or underflow with +/-/*).
  • Let bindings should use lexical scoping: evaluate all the binding expressions to values one by one, and after each, store a mapping from the given name to the corresponding value in both (a) the rest of the bindings, and (b) the body of the let expression. Identifiers evaluate to whatever their current stored value is.

There are several examples further down to make this concrete.

The compiler should stop and report an error if:

  • There is a binding list containing two or more bindings with the same name. The error should contain the string "Duplicate binding"
  • Shadowing with nested let binds are allowed. "Duplicate binding" panics are only when there are duplicates within the same bindings list of a let. Example: (let ((x 3)) (let ((x 1)) x)) results in 1 because x is shadowed; it is not a duplicate binding. (let ((y 3) (y 8)) 777) is a "Duplicate binding" error.
  • An identifier is unbound (there is no surrounding let binding for it) The error should contain the string "Unbound variable identifier {identifier}" (where the actual name of the variable is substituted for {identifier})

If there are multiple errors, the compiler can report any non-empty subset of them.

Here are some examples of Boa programs. In the "Abstract Syntax" parts, we assume that the program has appropriate use statements to avoid the Expr:: and other prefixes in order to write the examples compactly.

Example 1

Concrete Syntax

5

Abstract Syntax

Number(5)

Result

5

Example 2

Concrete Syntax

(sub1 (add1 (sub1 5)))

Abstract Syntax

UnOp(Sub1, Box::new(UnOp(Add1, Box::new(UnOp(Sub1, Box::new(Number(5)))))))

Result

4

Example 3

Concrete Syntax

(let ((x 5)) (add1 x))

Abstract Syntax

Let(vec![("x".to_string(), Number(5))],
  Box::new(UnOp(Add1, Box::new(Id("x".to_string())))))

Result

6

More examples

(sub1 5)
# as an expr
UnOp(Sub1, Box::new(Number(5)))
# evaluates to
4

(let ((x 10) (y 7)) (* (- x y) 2))
# as an expr
Let(vec![("x".to_string(), Number(10)), ("y".to_string(), Number(7))],
    Box::new(BinOp(Times, Box::new(BinOp(Minus, Box::new(Id("x".to_string())),
                          Box::new(Id("y".to_string())))), Box::new(Number(2)))));
# evaluates to
6

Implementing an AOT Compiler for Boa

You have a starter codebase from Adder that has several pieces of infrastructure:

  • A main program (main.rs) that uses the parser and compiler to produce assembly code from an input Boa text file.
  • A Makefile and a runner (runtime/start.rs) that you can modify from Adder. You may modify your Makefile to add new commands.
  • You will add your own tests by creating new .snek files in the tests/ directory and compiling them like we did in Adder, but with an extra argument (-c) to specify cargo run -c in.snek out.s.
  • To speed up the testing, you can write your own automated unit testing infrastructure in the tests/ directory.

Writing the Parser

The parser will be given a S-expression representing the whole program, and must build a AST of the Expr data type from this S-expression.

An S-expression in Rust is of the following type:

pub enum Sexp {
    Atom(Atom),
    List(Vec<Sexp>),
}
pub enum Atom {
    S(String),
    I(i64),
    F(f64),
}

Thus, an example S-expression that could be parsed into a program would be as follows

List(vec![Atom("let"), List(vec![List(vec![Atom("x"), Atom("5")])]), Atom("x")])

which corresponds to

(let ((x 5)) x)

in Boa or

{
    let x = 5;
    x
}

in Rust.

This should then parse to the AST

Let(vec![("x".to_string(), Number(5))], Id("x".to_string()))

which can then be compiled.

Since most S-expressions are lists, you will need to check the first element of the list to see if the operation to perform is a let, add1, *, and so on. If an S-expression is of an invalid form, (i.e. a let with no body, a + with three arguments, etc.) panic with a message containing the string "Invalid".

You can assume that an id is a valid string of form [a-zA-z][a-zA-Z0-9]*. You will, however, have to check that the string does not match any of the language's reserved words, such as let, add1, and sub1.

The parsing should be implemented in

fn parse_expr(s: &Sexp) -> Expr {
    todo!("parse_expr");
}

You can also implement a helper function parse_bind

fn parse_bind(s: &Sexp) -> (String, Expr) {
    todo!("parse_bind");
}

which may be helpful for handling let expressions.

Writing the AOT Compiler

The primary task of writing the Boa compiler is simple to state: take an instance of the Expr type and turn it into a list of assembly instructions. Start by defining a function that compiles an expression into a list of instructions:

fn compile_to_instrs(e: &Expr) -> Vec<Instr> {
    todo!("compile_to_instrs");
}

which takes an Expr value (abstract syntax) and turns it into a list of assembly instructions, represented by the Instr type. Use only the provided instruction types for this assignment; we will be gradually expanding this as the quarter progresses. The compiled Instr vector can be translated into both a string representation of the assembly code and dynasm instructions for Part 2's JIT compilation.

Note: For variable bindings, we used im::HashMap<String, i32> from the im crate. We use the immutable HashMap here to make nested scopes easier because we found it annoying to remember to pop variables when you leave a scope. You're welcome to use any reasonable strategy here.

The other functions you need to implement are:

fn instr_to_str(i: &Instr) -> String {
    todo!("instr_to_str");
}

fn val_to_str(v: &Val) -> String {
    todo!("val_to_str");
}

They render individual instances of the Instr type and Val type into a string representation of the instruction. This second step is straightforward, but forces you to understand the syntax of the assembly code you are generating. Most of the compiler concepts happen in the first step, that of generating assembly instructions from abstract syntax. Feel free to ask or refer to on-line resources if you want more information about a particular assembly instruction!

After that, put everything together with a compile function that compiles an expression into assembly represented by a string.

fn compile(e: &Expr) -> String {
    todo!("compile");
}

Assembly instructions

The Instr type is defined below. The assembly instructions that you will have to become familiar with for this assignment are:

  • IMov(Val, Val) — Copies the right operand (source) into the left operand (destination). The source can be an immediate argument, a register or a memory location, whereas the destination can be a register or a memory location.

    Examples:

      mov rax, rbx
  mov [rax], 4

  • IAdd(Val, Val) — Add the two operands, storing the result in its first operand.

    Example: add rax, 10

  • ISub(Val, Val) — Store in the value of its first operand the result of subtracting the value of its second operand from the value of its first operand.

    Example: sub rax, 216

  • IMul(Val, Val) — Multiply the left argument by the right argument, and store in the left argument (typically the left argument is rax for us)

    Example: imul rax, 4

Running

With the -c flag, run cargo run -- -c test.snek test.s to compile your snek file into assembly. You can modify your Makefile to add a command to do this for you.

$ cargo run -- -c test/add1.snek test/add1.s
$ cat test/add1.s

section .text
global our_code_starts_here
our_code_starts_here:
  mov rax, 131
  ret

To actually evaluate your assembly code, we need to link it with runtime.rs to create an executable. This is covered in the Makefile from Adder.

$ make test/add1.run
nasm -f elf64 test/add1.s -o runtime/our_code.o
ar rcs runtime/libour_code.a runtime/our_code.o
rustc -L runtime/ runtime/start.rs -o test/add1.run

Finally you can run the file by executing to see the evaluated output:

$ ./test/add1.run
131
  • Note: Locally on arm macs, to target with Rosetta 2, you need to use:
cargo run --target x86_64-apple-darwin -- -c test.snek test.s

and

nasm -f macho64
ar rcs runtime/libour_code.a runtime/our_code.o
rustc --target x86_64-apple-darwin -L tests/ -lour_code:$* runtime/start.rs -o tests/$*.run

OR you can simply add a new directory and file .cargo/config.toml with the following contents:

[build]
target = "x86_64-apple-darwin"

And run all commands normally.

Part 2: Dynamic Compilation

Now that you have an AOT compiler with all of the Boa language features, you can use it to generate machine code and execute it at runtime. Just like in Adder, you will use the dynasm crate to generate machine code at runtime.

The dynasm crate provides macros that allow you to write assembly-like code that gets compiled into a vector of bytes representing machine instructions. You can then execute this machine code by casting it to a function pointer using mem::transmute. This is exactly how you evaluate the Boa program directly without generating an assembly file or linking it to runtime.rs!

Writing the JIT Compiler

Notice how we used the Instr type to represent assembly instructions in Part 1. This abstraction is useful for generating assembly code as a string. But how about for JIT compilation, where we need to generate machine code directly with dynasm's macros? Using a vector of Instr, instead of generating strings, is it possible to generate machine code directly? It may be useful to have a function like this:

fn instr_to_asm(i: &Instr, ops: &mut dynasmrt::x64::Assembler) {
    todo!("instr_to_asm");
}

Ideally, it would be nice to generate dynasm from all possible instructions; you may find it useful to restrict it to just instructions that you expect your compiler to produce. This may involve a lot of boilerplate; it's a good place to see if a LLM can do some boring work for you.

Although this is one approach, feel free to use any strategy you would like!

Running

Now with the -e flag, run cargo run -- -e test.snek to compile your snek file and directly execute it. You can modify your Makefile to also include this command.

$ cargo run -- -e test/add1.snek
131

Here we have already evaluated our program at runtime! Notice that we did not link it to runtime.rs to create an executable.

We also will include a -g with cargo run -- -g test.snek test.s flag that will do both AOT and JIT compilation. This is for debugging purposes, since we can evaluate Boa code directly at runtime and print out the (hopefully correct) generated assembly that should produce the same evaluation. In all, your AOT and JIT compilers should be producing the same results.

$ cargo run -- -g test.snek test.s
131
$ cat test/add1.s

section .text
global our_code_starts_here
our_code_starts_here:
  mov rax, 131
  ret

Notice how it both evaluates our program and writes to test.s.

  • Note: Locally on arm macs, make sure to target the correct architecture for dynasm also with --target x86_64-apple-darwin.

Part 3: REPL (Hydra)

A REPL stands for Read, Evaluate, Print, Loop. This is where our JIT compiler shines, and we will be iteratively improving upon this for our next assignments.

Writing the REPL

With the io library, we can read input from the user. We can then parse the input into an Expr, compile it to machine code, and execute it at runtime. Finally, we print the result and loop back to reading input from the user again.

You may want to reuse your dynasmrt::x64::Assembler from the previous prompt instead of reinitilizing it each prompt. This is not required for now, but will be incredibly useful for the next assignments. Below is the same way to execute dynasm code without deconstructing the Assembler ops.

let start = ops.offset();

... // code gen with dynasm

dynasm!(ops ; .arch x64 ; ret);
// instead of finalize(), we commit()
ops.commit().unwrap();
let reader = ops.reader();
let buf = reader.lock();
let jitted_fn: extern "C" fn() -> i64 = unsafe { mem::transmute(buf.ptr(start)) };
let result = jitted_fn();
// Ownership for ops can continue!

Notice how we get a reader from the Assembler. This is our thread safe method for reading our executable memory buffer. Remember to update your start offset before new code generation to mark where the new executable code begins!

Here are some requirements for our REPL:

  • A prompt for our user (maybe > or $ or anything else you would like to customize).
  • If we ever encounter an error, we will print out the error message and continue the loop. This means we need graceful error handling in our REPL.
  • exit or quit will exit the REPL.
  • New type define for defining top-level variables across multiple prompts. This can be extended from Expr, or your own REPL type (maybe like ReplEntry from class).

The Define Statement

Define(String, Box<Expr>)

Our new type, define, is something unique to the REPL. The expression (define x expr) will define a top-level variable x to be the result of evaluating expr. This variable can then be used in future REPL prompts.

  • define will be top-level only. Otherwise, return an error message containing the string "Invalid".
  • We cannot redefine the same variable twice. If we try to do so, we will print out an error message containing the string "Duplicate binding".
  • We can shadow define d variables in nested scopes with let expressions.
  • You must store define d variable immediate values on the heap somewhere and then refer to it immediately when compiling the Id. This is an optimiation so we do not use the stack.

Running

With the -i flag, run cargo run -- -i to enter the REPL. You can then type in Boa expressions and see their evaluated results immediatley. Rather than input/output files, we specify -i for interactive.

$ cargo run -- -i
> (let ((x 5)) (+ x 10))
15
> (define x (add1 46))  // nothing is printed
> x
47
> (+ x 4)
51
> (define x 100)   // error but no exit
Duplicate binding
> (let ((x 10)) x)   // shadowing
10
> (hello           // parse error but no exit
Invalid: parse error
> quit
  • Note: Locally on arm macs, make sure to target the correct architecture (and keep an eye on if your cargo test is doing the same)!

Ignoring or Changing the Starter Code

You can change a lot of what we describe above; it's a (relatively strong) suggestion, not a requirement. You might have different ideas for how to organize your code or represent things. That's a good thing! What we've shown in class and this writeup is far from the only way to implement a compiler.

To ease the burden of grading, we ask that you keep the following in mind: we will grade your submission (in part) by copying our own tests/ directory in place of the one you submit and running with all 4 flags:

cargo run -- -c tests/test1.snek tests/test1.s
cargo run -- -e tests/test1.snek
cargo run -- -g tests/test1.snek tests/test1.s
cargo run -- -i

And producing corresponding executable files and outputs from generated assembly. It doesn't rely on any of the data definitions or function signatures in src/main.rs. So with that constraint in mind, feel free to make new architectural decisions yourself.

Strategies, and FAQ

Working Incrementally

If you are struggling to get started, here are a few ideas:

  • Try to tackle features one at a time. For example, you might completely ignore let expressions at first, and just work on addition and numbers to start. Then you can work into subtraction, multiplication, and so on.
  • Some features can be broken down further. For example, the let expressions in this assignment differ from the ones in class by having multiple variables allowed per let expression. However, you can first implement let for just a single variable (which will look quite a bit like what we did in class!) and then extend it for multiple bindings.
  • Use git! Whenver you're in a working state with some working tests, make a commit and leave a message for yourself. That way you can get back to a good working state later if you end up stuck.
  • For AOT compilation, first check if your generated .s assembly is equivalent to the Instr vector, and for JIT, check if your Instr instructions are pattern matched correctly. Make sure you call the dynasm conventions from Adder correctly.

FAQ

What should (let ((x 5) (z x)) z) produce?

From the PA writeup: “Let bindings should evaluate all the binding expressions to values one by one, and after each, store a mapping from the given name to the corresponding value in both (a) the rest of the bindings, and (b) the body of the let expression. Identifiers evaluate to whatever their current stored value is.”

Do Boa programs always have the extra parentheses around the bindings?

In Boa, there's always the extra set of parens around the list.

Can we write additional helper functions?

Yes.

Do we care about the text return from panic?

Absolutely. Any time you write software you should strive to write thoughtful error messages. They will help you while debugging, you when you make a mistake coming back to your code later, and anyone else who uses your code.

As for the autograder, we expect you to catch parsing and compilation errors. For parsing errors you should panic! an error message containing the word Invalid. For compilation errors, you should catch duplicate binding and unbound variable identifier errors and panic! Duplicate binding and Unbound variable identifier {identifier} respectively. We've also added these instructions to the PA writeup.

How should we check that identifiers are valid according to the description in the writeup?

From the PA writeup: “You can assume that an id is a valid string of form [a-zA-z][a-zA-Z0-9]*. You will, however, ...”

Assume means that we're not expecting you to check this for the purposes of the assignment (though you're welcome to if you like).

What should the program () compile to?

Is () a Boa program (does it match the grammar)? What should the compiler do with a program that doesn't match the grammar?

What's the best way to test? What is test case testing?

A few suggestions:

  • First, make sure to test all the different expressions as a baseline
  • Then, look at the grammar. There are lots of places where <expr> appears. In each of those positions, any other expression could appear. So let can appear inside + and vice versa, and in the binding position of let, and so on. Make sure you've tested enough nested expressions to be confident that each expression works no matter the context
  • Names of variables are interesting – the names can appear in different places and have different meanings depending on the structure of let. Make sure that you've tried different combinations of let naming and uses of variables.

My tests non-deterministically fail sometimes

You are probably running cargo test instead of cargo test -- --test-threads 1. The testing infrastructure interacts with the file system in a way that can cause data races when tests run in parallel. Limiting the number of threads to 1 will probably fix the issue.

Grading

Update: To expedite grading and review, we're adding a new constraint. Your solution must be able to run cargo test. You can use our testing infrastructure https://github.com/ucsd-cse131-fa25/test-starter, or use your own. However, you must be able to:

  • Run cargo test to run multiple test files
  • Make it clear in the README how we can add a new test that will be run with cargo test

This matches Rust development practices and makes it a lot easier for us to review your submission.

We'll combine our own tests with some amount of manual grading involving looking at your testing and implementation strategy. You should have your own thorough test suite (it's not unreasonable to write many dozens of tests; you probably don't need hundreds), and you need to have recognizably implemented a compiler. For example, you could try to calculate the answer for these programs and generate a single mov instruction: don't do that, it doesn't demonstrate the learning outcomes we care about.

Any credit you lose will come with instructions for fixing similar mistakes on future assignments.

Happy hacking!
